孟加拉公司采购光伏项目 -- 20230522

光伏 项目

孟加拉公司采购光伏项目


具体要求请联系张小姐:

Lynne<jrs8@jrs-sourcing.com>

Tel,WeChat:13530128923


BOQ for 6505 KWp ROOFTOP SOLAR POWER PLANT

ITEM Specifications Descriptions / Brands Unit  Qty  Remarks
1. Solar Module
PV Module Brand Canadian/ Trina/ JA Solar/ Jinko/ AE Solar Nos 11535
Module Type n-type
Dimension 2278±2mmx1134±2mmx30±1 mm
Module Capacity (Watt) 570/575/580
2. Solar Inverter
Shed-12
Inverter (110 KW) only for Shed-12 Brand SMA Nos 18 The existing plant has been commissioned with SMA, thereby rest of plant will be commissioned with SMA
Origin Germany
Protection Class IP66
Warranty 5
Inverter Capacity (Watt) 110000
Total Watt
Rest of Shed/Building
Inverter (110 KW) Brand SMA Nos 29 SMA or Huawei, any of them is compatible with the projects. Any brand can be considered.
Origin Germany
Protection Class IP66
Warranty 5
Inverter Capacity (Watt) 110000
Total Watt
Inverter (50 KW) Brand SMA Nos 2
Origin Germany
Protection Class IP66
Warranty 5
Inverter Capacity (Watt) 50000
Total Watt
AC & DC Surge Protection device for SMA Core-1, 50 KW Inverter     Set 5
Alternative
Inverter (100 KW) Brand Huawei Nos 31
Origin China
Protection Class IP66
Warranty 5
Inverter Capacity (Watt) 100000
Total Watt
Inverter (50 KW) Brand Huawei Nos 3
Origin China
Protection Class IP66
Warranty 5
Inverter Capacity (Watt) 60000
Total Watt
3. Module Mounting Structure & Walkway
Mounting Structures for Industrial Shed Roof Aluminium R06 Rail-2400 (W25 x H50 x L2400mm, Al6005-T5, Material: Aluminum 6005-TS & Stainless Steel 304)   Nos 6254
Aluminium R06 Rail-3200 (W25 x H50 x L3200mm, Al6005-T5,  Material: Aluminum 6005-TS & Stainless Steel 304) Nos 8993
L Foot (include 1pc EPDM rubber, 1pc M6.3x80mm self drilling screw (SUS410) and 1pc M8x25mm bolt, washer, Alu nut, Al6005-T5, Material: Aluminum 6005-TS & Stainless Steel 304) Nos 51994
Mid Clamp (T-35mm, Panels Al6005-T5)  Nos 28631
Grounding clip for Mid Clamp (Grade- SUS304) Nos 28631
End Clamp  (T-35mm, Panels Al6005-T5) Nos 1357
Rail Jointer (L-200 mm, Alu 6005-T5) Nos 6486
Grounding Clip (Grade- SUS304) Nos 1500
Grounding Lug (L-20mm) Nos 1500
Walkway FRP- Flush Edge  (L3660xW375xH38mm, Mesh size:38x38) Nos 1864
M Clamp for walkway (To fixed FRP wallkway) Nos 23487
C Clamp for Walkway (Material- SUS304, To connect FRP walkway) Nos 3150
4. Monitoring & Communication System
Data Manager for Online monitoring solution with power supply SMA: Data Manager M Model: EDMM-10
Input: 100 V to 240 VAC / 45 Hz to 65 Hz with power supply 24 VDC / 2.5 A
Country of Origin: Germany
Set 8 SMA data manager is compatible with SMA inverter and Huawei smart logger is thereby compatible with Huawei inverter.
Alternative
Huawei: Smartlogger  Model: Smart Logger 3000A01EU
Power supply DC: 12 V / 24 V
Country of Origin: China
Set 6
DG-PV Synchroniser/ Fuel Saver controller     Nos 1
Weather monitoring station PVmet-200   Nos 1
Wi-Fi Router     Nos 8
5. Comunication Cables Brand- Laap / HangTon / Zion / NINGBO Holden / Equivalent Cables
Shield Cable 2x1.5 SQMM, XLPE Insulated shielded
Stranded conductor, Armoured Cables, RS 485
Meter 5000
Cat-6 Cable   Meter 2500
6. DC Cables
DC cables: Panel to Panel Solar DC Cable- 1x4 rm
Spec.- Conductor: Flexible Annealed Tinned Copper (Class-5), UV resistance XLPE/XLPO, Rated Voltage: 0.6/1kVAC, Rated DC Voltage: 1.5 kV, Maximum Permitted DC Voltage: 1.8 kV.
Meter 119800
7. AC Cables
AC Cables PVC Cable 1x95 rm (NYY, FR) Meter 3000
PVC Cable 1x185 rm (NYY, FR) Meter 6000
PVC Cable 1x300 rm (NYY, FR) Meter 3000
PVC Cable 5x35 (NYY,FR) Meter 1000
PVC Cable 1x16 rm (BYA, FR), Green-Yellow Meter 3000
8. Energy Meter
Meter for SDB Schneider  Model: PM 5330, Schneider Nos 16
Meter for close-loop feedback Siemens Model: PAC 2200 (Modbus), Siemens Nos 2
9. Connectors
MC4 Connectors TUV certified with male connector on positive and female connector on negative terminals, 1000V, 15A rated current, IP68 Brand:
Class: IP65/IP68 (1m,1h)
Country of Origin: China
Country of Manufacture: China
Set 1000 MC4 connectors & PV Module should be same brand
10. Breakers & Protection Devices
AC SPD Surge Protective Device
Type-2 (Class- B), 40KA, Din rail mounted.
Model: OVR T2 3N 40-350 P TS QS
Product ID: 2CTB803983R0500
Brand- ABB / Siemens / Schneider / Equivalent Nos 12
MCCB- TP 250A, Adjustable, 36 KA Nos 50
125A, Adjustable, 36 KA Nos 10
630A, Adjustable, 36 KA Nos 6
800A, Adjustable, 50 KA Nos 7
1250A, Adjustable, 50 KA Nos 6
MCB-SP 2A Nos 40
ACB 2000 A Fixed Type, 66 KA, LSIG Protection Nos 1
2500 A Fixed Type, 66 KA, LSIG Protection Nos 1
4000 A Fixed Type, 85 KA, LSIG Prorection  Nos 1
DC Fuse Holder & Fuse 1000VDC, 32A, 7.2 KV RATED FERRULE Base Brand- Mersen / Equivalent Nos 2400
